0139 PSC series AC Motor
Main applications: Household appliances, fans, pumps, and small machinery. Frame size: Φ80~Φ139 PSC (permanent split capacitor) motor used in fan and ventilation.
| Model | Voltage (V) | Frequency (Hz) | Nominal Output Power (W) | Current (A) | Rated Speed (r/min) | Capacitor (μF/V) |
|---|---|---|---|---|---|---|
| YYF139-180-6D | 208-230 | 60 | 180 | 2.1 | 1075/1SP | 5µF/370V |
| YYF139-250-6D | 208-230 | 60 | 250 | 3 | 1075/1SP | 7.5µF/370V |
| YYF139-370-6D | 208-230 | 60 | 370 | 3.7 | 1075/1SP | 10µF/370V |
| YYF139-550-6D | 208-230 | 60 | 550 | 4.5 | 1075/1SP | 15µF/370V |
| YYF139-750-6D | 208-230 | 60 | 750 | 5.2 | 1075/1SP | 15µF/370V |
| YYF139-180-4D | 208-230 | 60 | 180 | 1.8 | 1550/1SP | 5µF/370V |
| YYF139-250-8D | 208-230 | 60 | 250 | 2 | 825/1SP | 12.5µF/370V |
| YYF139-75-6D | 208-230 | 60 | 75 | 0.09 | 900/2SP | 5µF/370V |
| YYF139-180-6D | 208-230 | 60 | 180 | 1.5 | 1075/2SP | 7.5µF/370V |
| YYF139-180-6D | 208-230 | 0 | 180 | 1.82 | 1075/2SP | 7.5µF/370V |
| YYF139-250-6D | 208-230 | 60 | 250 | 2.4 | 950/2SP | 10µF/370V |
| YYF139-370-6D | 208-230 | 60 | 370 | 2.9 | 1075/3SP | 10µF/370V |
| YYF139-550-6D | 208-230 | 60 | 550 | 5.4 | 1075/3SP | 15µF/370V |
| YYF139-55-6D | 208-230 | 60 | 550 | 4.3 | 1100/3SP | 15µF/370V |
| YYF139-120-6S | 208-230 | 60 | 120 | 1.3 | 1075/3SP | 5µF/370V |
| YYF139-180-6S | 208-230 | 60 | 180 | 1.6 | 1075/3SP | 5µF/370V |
| YYF139-250-6S | 208-230 | 60 | 250 | 2.5 | 1075/3SP | 5µF/370V |
| YYF139-370-6S | 208-230 | 60 | 370 | 3.2 | 1075/3SP | 7.5µF/370V |
| YYF139-100-4S | 220 | 50 | 100 | 0.95 | 1400/3SP | 8µF/450V |
| YYF139-250-4S | 220 | 50 | 250 | 1.65 | 1350/3SP | 12.5µF/450V |
| YYF139-180-4D | 220 | 50 | 180 | 1.5 | 1350/1SP | 5µF/450V |
| YYF139-250-4D | 220 | 50 | 250 | 2 | 1350/1SP | 8µF/450V |
| YYF139-370-4D | 220 | 50 | 370 | 3.2 | 1350/1SP | 10µF/450V |
| YYF139-550-4D | 220 | 50 | 550 | 5 | 1350/1SP | 10µF/450V |
