0105 PSC series AC Motor
Main applications: Household appliances, fans, pumps, and small machinery. Frame size: Φ80~Φ139 PSC (permanent split capacitor) motor used in fan and ventilation.
| Model | Voltage (V) | Frequency (Hz) | Nominal Output Power (W) | Current (A) | Rated Speed (r/min) | Capacitor (μF/V) |
|---|---|---|---|---|---|---|
| YYF105-35-4S | 220-240 | 50 | 35 | 0.45 | 1100/3SP | 1.5µF/450V |
| YYF105-55-4S | 220-240 | 50 | 55 | 0.7 | 1100/1SP | 2.5µF/450V |
| YYF105-75-4S | 220-240 | 50 | 75 | 0.7 | 1200/1SP | 4µF/450V |
| YYF105-70-4D | 220-240 | 50/60 | 70 | 0.7 | 1425/1725/1SP | 4µF/450V |
| YYF105-90-4D | 220-240 | 50 | 90 | 0.9 | 900/1SP | 6µF/450V |
| YYF105-150-2D | 220-240 | 50 | 150 | 1.1 | 1350/1SP | 6µF/450V |
